Digital Multimeter w/Lo-Z
Key FeaturesSpecificationsReviews
Auto range to millivolts and milliamp ranges
Contact temperature measurement from -40 to 752°F
Measures up to 600A AC
600µa DC for Flame Rectification
High Contrast, White on Black Display with Backlight for easy reading
Lo-Z measurement to eliminate ghost voltage
Rugged over-molding increases durability and user grip
True RMS for accurate measurement in all applications
Wide Voltage range to 600 volts AC/DC
Powered by (2) AA batteries
5-Year Warranty
You May Also Like...
Product Specifications
Tool Warranty
5 Years
Battery Type
Alkaline (AA)
Display Type
Digital
Switch Type
Dial
Material Composition
Plastic
Length
10 in
Weight
1.565 lb
Height
3.4 in
Width
6.7 in
TRMS
Yes
Current AC DC
10.00A
Voltage AC DC
600V
Frequency
10 Hz - 50.00 kHz
Resistance
40MΩ
Continuity
Audible
Capacitance
1,000μF
Contact Temperature
-40° F to 752° F (-40° C to 400° C)
Safety Category Rating
CAT III 600V
Lo Z
Yes
Backlight
Yes
HOLD MIN MAX
Yes
Bargraph
Yes
Rugged Overmolding
Yes
Accessory Attachment
Magnetic Meter Holder
Calibration Needed
Yes - Recommend calibration service once every year
