Key FeaturesSpecificationsReviews
True-RMS for accurate measurement in all applications
Wide Voltage range to 600 AC /DC volts
Resistance range from 600 ohm to 40 Mohm
Auto Range to mV
Frequency measurements from 10Hz to 50kHz
Current Measurement to 10A AC/DC
Rugged over-molding increases durability and user grip
CAT III 600V for increased safety
Capacitance to 1000 ?F
You May Also Like...
Product Specifications
Tool Warranty
5 Years
Battery Type
Alkaline (AA)
Display Type
Digital
Switch Type
Dial
Material Composition
Plastic
Length
10.55 in
Weight
1.38 lb
Height
2.7 in
Width
6.05 in
TRMS
Yes
Current AC DC
10.00A
Frequency
2.00 Hz - 50.00 kHz
Resistance
40MΩ
Continuity
Audible
Capacitance
1,000μF
Safety Category Rating
CAT III 600V
Voltage AC
6.00mV - 600V
Voltage DC
600.0mV - 600V
Backlight
Yes
HOLD MIN MAX
Yes
Bargraph
Yes
Rugged Overmolding
Yes
Accessory Attachment
Magnetic Meter Holder
Calibration Needed
Yes - Recommend calibration service once every year
