M18 FUEL™ Barrel Grip Jig Saw (Tool Only)

The M18 FUEL™ Barrel Grip Jig Saw combines power, blade speed and precision, to provide the highest quality cuts in a wide variety of materials. The M18 FUEL™ Barrel Grip Jig Saw leverages the POWERSTATE™ Brushless Motor and REDLINK PLUS Intelligence to provide higher blade speed than corded jig saws at 3500 strokes per minute for clean controlled cuts with minimized chipping or bucking. Leveraging the M18™ REDLITHIUM™ XC5.0 battery the M18 FUEL™ D-Handle Jig Saw provides up to 105 linear feet of cutting in ¾” laminated particle board, delivering all day productivity with less trips to the charger. The saw features tool-less blade change, tool free bevel adjust with detents at 0°; 15°; 30°; and 45° as well as an LED light and on/off blower to keep the cut line visible while cutting.

Includes

(1) M18 FUEL™ Barrel Grip Jig Saw (Tool Only)(2737B-20)

(1) Anti-Splinter Guard

(1) Dust Collection Tube

(1) Dust Cover

(1) Hex Wrench

(1) Shoe Guard

M18 FUEL™ Barrel Grip Jig Saw (Tool Only)

Key FeaturesSpecificationsReviews

M18 FUEL™ Barrel Grip Jig Saw

HigherBLADE SPEEDTHAN CORDED

POWERTO CUTHARD MATERIALS

CUTS UP TO105 FTPER CHARGE

Click a Number for Details

HIGHER BLADE SPEED THAN CORDED

POWERSTATE Motor delivers higher sustained blade speed than 7A corded
Electronics continuously monitor speed and torque, maintaining up to 3,500 SPM in tough applications

2737B-20, 2737B-21 - M18 Fuel Jigsaw, Barrel Grip

POWER TO CUT HARD MATERIALS

Power to take on materials like hardwoods and metal without bogging down

CUTS UP TO 105FT PER CHARGE with M18 REDLITHIUM XC 5.0

Battery delivers up to 105ft of cutting in ¾” laminated particle board

PERFORMANCE DRIVEN.
TRADE FOCUSED.
SYSTEM WIDE.

4 position orbital cutting provides versatility for application specific cutting

Accepts T-Shank jig saw blades

Ambidextrous switches on the left and right sides provide easy access to power the tool on or off from multiple hand positions

Compatible with over 150+ tools on the M18™ Platform

Features 6 speed settings 0-3500 strokes per minute and an auto-control start feature that starts slow and ramps to full speed when the electronics detect that the blade is in material

Hex key on-board for quick bevel changes.

Includes dust cover and dust extraction tube

LED light illuminates the cut line

On/Off cut line blower keeps the cut line clear of debris, and allows user to turn off blower when using dust extraction

Positive stops at 0°, 15°, 30° and 45° ensure accurate bevel angles.

POWERSTATE brushless motor: Increased SPM and the power to cut hard materials, including hardwoods and metals

Provides optimized performance and overload protection using total system communication between tool, battery and charger

REDLITHIUM™ battery technology: superior pack construction, electronics and performance deliver more work per charge and more work over pack life than nay battery on the market

REDLINK™ plus intelligence: the most advanced system of cordless power tool electronics; provides optimized performance and overload protection using total system communication between tool, battery and charger

Product Specifications

Power Source

Cordless

Motor Type

Brushless

Handle Type

Barrel Grip

Material Composition

Metal

Length

11.7 in

Weight

4.59 lb

Height

7.3 in

Width

3.2 in

Badge Branding

FUEL™

Fuel

Yes

Voltage

18V

Brushless

Yes

Battery System

M18

M18 FUEL™ Barrel Grip Jig Saw (Tool Only)
