M18 FUEL™ QUIK-LOK™ Attachment System
MULTIPLE ATTACHMENTS POWERED BY A SINGLE HEAD
Designed to meet the needs of landscape maintenance professionals, the M18 FUEL™ QUIK-LOK™ Attachment System is a versatile outdoor power equipment system featuring multiple attachments powered by a single M18 Fuel™ Power Head. With the M18 FUEL™ QUIK-LOK™ Attachment System, you have the capability to switch between multiple attachments including a string trimmer, edger, hedge trimmer and pole saw to complete a wide range of applications.
The M18 FUEL™ QUIK-LOK™ Attachment System utilizes the most advanced cordless technology to deliver best-in-class power and run-time for landscaping and trade professionals, achieving instantaneous throttle response and outperforming higher voltage platforms
Vs. GAS
- 3016-21ST
M18 FUEL™ String Trimmer w/ QUIK-LOK™ Kit
- 3016-21PS
M18 FUEL™ Pole Saw w/ QUIK-LOK™ Kit
Power Head Kits
Attachments
Power Head Kits
Attachments
- M18 FUEL™ String Trimmer w/ QUIK-LOK™ Kit3016-21ST
- POWERSTATE Brushless Motor delivers more power than 31cc gas powerheads
- Compatible with all 13 Milwaukee QUIK-LOK attachments, making QUIK-LOK the most capable attachment system on the market
- Part of the M18 System, featuring over 275+ tools
- Reaches full throttle in under 1 second, providing unmatched responsiveness and productivity
- Balanced design optimized to increase control and reduce user fatigue
- 3-speed settings and variable speed trigger for increased control
- Max RPM of 6,200
- Features the Milwaukee® Easy Load Trimmer Head
- Adjustable cutting blade for a 16" or 14" swath, maximizing either power or runtime
- Line Diameter: 0.080" / 0.095"
- Robust construction to withstand daily use by professional landscapers
- Advanced air-cooling system to sustain demanding applications for longer
- M18 FUEL™ Pole Saw w/ QUIK-LOK™ Kit3016-21PS
- POWERSTATE Brushless Motor delivers more power than 31cc gas powerheads
- Compatible with all 13 Milwaukee QUIK-LOK attachments, making QUIK-LOK the most capable attachment system on the market
- Part of the M18 System, featuring over 275+ tools
- Reaches full throttle in under 1 second, providing unmatched responsiveness and productivity
- Balanced design optimized to increase control and reduce user fatigue
- 7'-10' of reach with included extension attachment
- 10", 3/8" low-profile pitch, .043" gauge cutting system
- 4600 RPM
- Automatic bar oiler and translucent oil reservoir
- Branch Hook for removing stuck branches after cutting
- Robust construction to withstand daily use by professional landscapers
- Advanced air-cooling system to sustain demanding applications for longer
- M18 FUEL™ Power Head w/ QUIK-LOK™3016-20
- POWERSTATE Brushless Motor delivers more power than 31cc gas powerheads
- Compatible with all 13 Milwaukee QUIK-LOK attachments, making QUIK-LOK the most capable attachment system on the market
- Part of the M18 System, featuring over 275+ tools
- Reaches full throttle in under 1 second, providing unmatched responsiveness and productivity
- 3-speed settings and variable speed trigger for increased control
- Adjustable bail handle for optimized balance and ergonomics across all applications and user heights
- Robust construction to withstand daily use by professional landscapers
- Advanced air cooling system to sustain demanding applications for longer
- M18 FUEL™ QUIK-LOK™ String Trimmer Attachment49-16-2717
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Cutting Swath: 14" - 16"
- Easy Load Trimmer Head: Easy Line-Loading, Under 30 seconds
- Feed System: Bump Feed
- Length: 36.25"
- Line Diameter: 0.080" / 0.095"
- Protected Drive-Shaft: Provides Greater Durability To Drive-Shaft Against Damage From Drops and Storage Elements
- RPM: 0 - 4900 / 0 - 6200
- Weight: 3.75 lbs
- M18 FUEL™ QUIK-LOK™ 10" Pole Saw Attachment49-16-2720
- Automatic Oiler: For Proper Chain Lubrication and Increased Productivity
- Bar Length: 10"
- Branch Hook: For Added Cutting Leverage and Branch Removal
- Chain Gauge: .043"
- Chain Pitch: 3/8" Low Profile
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Easy Access Chain Tensioner: Quick Adjustments to Chain Tension
- Padded Grip: For Optimal Hand Placement and Increased Comfort
- RPM: 4,600
- Translucent Oil Reservoir: Clear visibility to oil levels
- M18 FUEL™ QUIK-LOK™ Articulating Hedge Trimmer Attachment49-16-2719
- Articulating Head Design: Adjustment Handle And Sliding Adjustment Collar Allow for 270° Blade Set Rotation, Delivering 13 Operating Positions and 1 Storage Position
- Blade Length: 20"
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Cut Capacity: 1"
- Length: 60"
- Padded Grip: For Optimal Hand Placement and Increased Comfort
- SPM: 3,500
- Tip Guard: Prevents Damage To Blade and Surrounding Work Area
- Weight: 5.8 lbs
- M18 FUEL™ QUIK-LOK™ Edger Attachment49-16-2718
- Adjustable Wheel: Optimizes Blade Depth and Tool Angle For Maximum Control
- Blade Size: 8"
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- High Strength Guard: Metal Alloy Guard Delivers Greater Durability And Includes Blade Indication For Cut-Line Visibility
- Length: 38"
- Mud Flaps: Prevents Dirt and Debris Kick-Back
- RPM: 3,900
- Skid Plate: Protects Gear Box From Concrete Contact
- Weight: 5.25 lbs
- M18 FUEL™ QUIK-LOK™ 3' Attachment Extension49-16-2721
- Compatible with QUIK-LOK™ Hedge Trimmer and Pole Saw Attachments
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Delivers 3' of additional reach
- Length: 40.5"
- Padded Grip: For Optimal Hand Placement and Increased Comfort
- Protected Drive-Shaft: Provides Greater Durability To Drive-Shaft Against Damage From Drops and Storage Elements
- QUIK-LOK™ Coupler: Positive-Locking Mechanism And Alignment Guide For fast, Tool Free Attachment Changes
- Weight: 1.95 lbs
- M18 FUEL™ QUIK-LOK™ Brush Cutter Attachment49-16-2738
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Blade Guard: Optimized design for best material containment
- Brush Cutter Blade: 4-Tooth Blade Design
- RPM: 0 - 4900 / 0 - 6200
- Protected Drive-Shaft: Provides Greater Durability To Drive-Shaft Against Damage From Drops and Storage Elements
- Alignment Label: Indicates when attachment is fully inserted into M18 FUEL™ Power Head
- Blade Diameter: 9"
- Weight: 3.66 lbs
- Length: 40.6"
- M18 FUEL™ QUIK-LOK™ Rubber Broom Attachment49-16-2740
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Rubber Paddles: Optimized paddle design for longer life
- Optimized Guard Design for Best Material Containment
- 23" Clearing Width
- Protected Drive-Shaft: Provides Greater Durability To Drive-Shaft Against Damage From Drops and Storage Elements
- Alignment Label: Indicates when attachment is fully inserted into M18 FUEL™ Power Head
- Length: 48.75"
- Weight: 16.2 pounds
- M18 FUEL™ QUIK-LOK™ Bristle Brush Attachment49-16-2741
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Bristles: Optimized Design for Longer Life
- Optimized Guard Design for Best Material Containment
- 23" Clearing Width
- Protected Drive-Shaft: Provides Greater Durability To Drive-Shaft Against Damage From Drops and Storage Elements
- Alignment Label: Indicates when attachment is fully inserted into M18 FUEL™ Power Head
- Length: 48.75"
- Weight: 14.4 pounds
- M18 FUEL™ QUIK-LOK™ Bed Redefiner Attachment49-16-2795
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Durable Steel Blade maintains a 2.75” deep x 3.0” wide Tapered Edge
- Part of the M18 FUEL™ QUIK-LOK™ Attachment System, featuring 13 different attachments for all-season versatility
- Adjustable Wheel: Optimizes Blade Depth and Tool Angle for Maximum Control
- Optimized Guard Design for Best Material Containment and Includes Blade Indication for Trench-Line Visibility
- Length: 35"
- Mud Flaps: Prevents Dirt and Debris Kick-Back
- RPM: 2,000
- Skid Plate: Protects Gear Box from Wear
- Weight: 6.4 lbs.
- Trench Depth: 2.75”
- Trench Width: 3.0”
- M18 FUEL™ QUIK-LOK™ Cultivator Attachment49-16-2739
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- 9" Steel Tines Optimized for longer life
- Part of the M18 FUEL™ QUIK-LOK™ Attachment System, featuring 13 different attachments for all-season versatility
- Optimized Guard Design for Best Material Containment
- 9” Tilling Width
- Four 9” Diameter, Four Tine Bolo Style Blades
- Length: 41.5”
- Weight: 9.4 lbs.
- M18 FUEL™ QUIK-LOK™ Hedge Trimmer Attachment49-16-2796
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Has the power to cut 3/4" Branches
- Part of the M18 FUEL™ QUIK-LOK™ Attachment System, featuring 13 different attachments for all-season versatility
- Compact Fixed Shaft Style Design
- Tip Guard: Prevents Damage to the Blade and Surrounding Work Area
- Blade Length: 20” to Clear More in a Single Pass
- Cut Capacity: 3/4”
- SPM: 3,500
- Length: 41.2”
- Weight: 4.3 lbs.
- M18 FUEL™ QUIK-LOK™ Reciprocator Attachment49-16-2794
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Designed for precise, close proximity trimming with a 1/2 inch cut capacity
- Part of the M18 FUEL™ QUIK-LOK™ Attachment System, featuring 13 different attachments for all-season versatility
- Blade Diameter: 9”
- Cut Capacity: 1/2”
- SPM: 1,200
- Length: 38”
- Weight: 5.2 lbs.
- M18 FUEL™ QUIK-LOK™ Blower Attachment49-16-2793
- Compatible with the M18 FUEL™ Power Head w/ QUIK-LOK™
- Delivers 500 CFM and 120 MPH
- Part of the M18 FUEL™ QUIK-LOK™ Attachment System, featuring 13 different attachments for all-season versatility
- Sound pressure rating of 59db(A) per ANSI B175.2
- Milwaukee™ Blower Nozzle Accessory Capable
- Length: 34”
- Weight: 4.6 lbs.
